Siemens 3RV2011-1JA10 Circuit Breaker
New
In stock2 unitsReady to ship
The SIEMENS SIRIUS 3RV2011-1JA10 is a compact motor protection circuit breaker featuring a 7–10 A adjustable overload release, 10 A rated operating current, up to 100 kA short-circuit breaking capacity, CLASS 10 tripping, and DIN rail mounting for reliable industrial motor protection.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| MNR | 3RV2 011-1JA10 |
| product brand name | SIRIUS |
| Series | 3RV2 |
| Product Type Designation | 3RV2 |
| Size | S00 |
| Design of the Product | For Motor Protection |
| Adjustable Overload Release | 7 to 10 A |
| Rated Operating Current | 10 A (AC3, 400V) |
| Switching Capacity | Up to 4kW at 400V (AC3); 2.2kW at 230V, 5.5kW at 500V, 7.5kW at 690V |
| Short Circuit Breaking Capacity (Icu) | Up to 100kA at 400V; 6kA at 690V |
| Auxiliary Contact | 2 Normally Open (2NO) |
| Trip Class | CLASS 10 |
| Mounting & Connections | Screw-and-snap mount on 35mm DIN rail; screw terminals |
| Dimensions | 97 x 45 x 97 mm |
| Condition | New |
| Stock key | JO-004 |
| SKU | 1093477 |
| Weight | 0,35 |
