Siemens 6ES7 522-1BH01-0AB0 Digital Output Module
New
Available on request
Digital Output Module
A compact and high-speed digital output module for SIMATIC S7-1500 PLC systems, providing 16 transistor outputs at 24 V DC for reliable industrial automation and control applications.6ES7522-1BH01-0AB0accessoriesAutomationComponentsControlDigitalIndustrialModuleOutputPLCS7-1500SiemensSimaticSystem
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Siemens SIMATIC S7-1500 Digital Output Module 6ES7522-1BH01-0AB0
A high-performance digital output module designed for advanced industrial automation systems. This module is part of the SIMATIC S7-1500 family and provides reliable transistor-based digital outputs for precise and fast signal switching in demanding control applications. Manufacturer: Siemens
Type: Digital Output Module
Family: SIMATIC S7-1500
MRN: 6ES7522-1BH01-0AB0
Product Type Designation: DQ 16x24VDC/0.5A HF
HW Functional Status: From FS02
Firmware Version: V1.1.0
| STEP 7 TIA Portal | Configurable / Integrated from V13 SP1 |
| STEP 7 | Configurable / Integrated from V5.5 SP3 |
| PROFIBUS GSD Version / Revision | V1.0 / V5.1 |
| PROFINET GSD Version / Revision | V2.3 |
| Supply Voltage (Rated, DC) | 24 V |
| Permissible Voltage Range (DC) | 19.2 V to 28.8 V |
| Current Consumption (Max.) | 30 mA |
| Output Voltage (Rated, DC) | 24 V |
| Power Loss (Typical) | 2 W |
| Type of Digital Output | Transistor |
| Number of Digital Outputs | 16 |
| Ambient Temperature (Horizontal Installation) | -30 °C to +60 °C (From FS03) |
| Width | 35 mm |
| Height | 147 mm |
| Depth | 129 mm |
