Siemens 6GK1503-3CB00 Profibus OLM/G12 V4.0

Siemens PROFIBUS OLM/G12 V4.0

The Siemens PROFIBUS OLM/G12 V4.0 (6GK1503-3CB00) is an optical link module designed for efficient communication in PROFIBUS networks. It is used to connect network components over fiber optic cables, providing a reliable and high-performance solution for industrial automation systems. This module is equipped with two optical interfaces for fiber optic cables, ensuring seamless and fast data transmission in demanding industrial environments.

Operating with a voltage of 24V and an operational current of 0.1A, the PROFIBUS OLM/G12 V4.0 ensures efficient power consumption, with a maximum consumed current of 0.2A at DC/24V. The module features multiple types of electrical connections for different network configurations: a 9-pin Sub-D socket for network components or terminal equipment, a 2-pole terminal block for measuring devices, and a 5-pole terminal block for power supply and signaling contacts. The propagation delay is optimized at 6.5 bits for fast and reliable communication.

With an IP40 protection class, this module is designed to withstand industrial conditions and can operate in temperatures ranging from 0 to 60°C. The compact dimensions (112 x 39.5 x 74.5 mm) make it suitable for integration into various industrial setups and control cabinets.

Manufacturer: Siemens

Type: PROFIBUS OLM/G12 V4.0

Model: 6GK1503-3CB00

Electrical Connection:

9-pin Sub-D socket for network components or terminal equipment

2-pole terminal block for measuring devices

5-pole terminal block for power supply and signaling contact

The Siemens PROFIBUS OLM/G12 V4.0 module is designed to provide efficient and reliable data transmission over optical fiber, ensuring robust communication for automation and control systems in industrial environments.
