SKF 24120 CC/W33 Spherical Roller Bearing
Manufacturer: SKF
Type: SPHERICAL ROLLER BEARING
Model: 24120-CC/W33
Dimensions
Bore Diameter d: 100 mm
Outer diameter D: 165 mm
Width B: 65 mm
Basic load ratings, radial:
Dynamic Cr: 468 kN
Static C0r: 640 kN
Limiting Speed: 3200 r/min
Reference speed: 2400 r/min
Fatigue load limit: 68 kN
Lubrication: W33, Annular groove and three lubrication holes in outer ring
Radial internal clearance: CC, Modified for duplex mounting with axial clearance greater than normal
Cage: Sheet metal
