SKF 3308 DMA Double ROW Angular Contact Ball Bearing
New
Available on request
Ball Bearing
SKF 3308DMA double row angular contact ball bearing with two-piece inner ring, 45° contact angle, and high load capacity for industrial applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SKF 3308DMA Double Row Angular Contact Ball Bearing
The SKF 3308DMA is a double row angular contact ball bearing designed to support combined radial and axial loads. Its two-piece inner ring construction and 45° contact angle provide high load capacity and stable performance in demanding industrial applications.
Manufacturer: SKF
Type: Double Row Angular Contact Ball Bearing With Two-Piece Inner Ring
Model: 3308DMA
| Bore Diameter (d) | 40 mm |
| Outer Diameter (D) | 90 mm |
| Width (B) | 36.5 mm |
| Contact Angle | 45° |
| Dynamic Load Rating (Cr) | 68,900 N |
| Static Load Rating (C0r) | 57,000 N |
| Limiting Speed | 7,000 rpm |
| Reference Speed | 8,000 rpm |
| Ring Type | Two-piece inner ring and one-piece outer ring |
| Cage | Machined metal |
