SKF 7010 CD/P4A Angular Contact Ball Bearing
New
Available on request
Angular Contact Ball Bearing
SKF 7010 CD/P4A Angular Contact Ball Bearing features a 50 mm bore diameter, 80 mm outer diameter, and a 15° contact angle. Ideal for high-speed, high-precision applications with dynamic load rating of 29.6 kN and attainable speeds of up to 28000 rpm.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SKF 7010 CD/P4A Angular Contact Ball Bearing
The SKF 7010 CD/P4A Angular Contact Ball Bearing is designed for high-speed, high-precision applications. With a 15° contact angle and a robust dynamic load rating, it is ideal for applications requiring durability and precise performance.
Manufacturer: SKF
Model: 7010 CD/P4A
Type: Angular Contact Ball Bearing
| Bore Diameter | 50 mm |
| Outer Diameter | 80 mm |
| Width | 16 mm |
| Basic Dynamic Load Rating | 29.6 kN |
| Basic Static Load Rating | 24 kN |
| Fatigue Load Limit | 1.02 kN |
| Attainable Speed (Grease Lubrication) | 17000 rpm |
| Attainable Speed (Oil-Air Lubrication) | 28000 rpm |
| Tolerance Class | P4A |
| Contact Angle | CD, 15° |
