SKF 7016 ACD/P4ATGB Angular Contact Ball Bearing
New
In stock1 unitReady to ship
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
Manufacturer: SKF
Type: super-precision Angular Contact ( spindle )Ball Bearing
Model: 7016 ACD P4A TG B
Bore Diameter: 80 mm
Outer Diameter: 125 mm
Thickness: 22 mm
Chamfer rmin: 1.1 mm
Contact Angle: 25°
Dynamic Cr: 62.4 kN
Static C0r: 58.5 kN
Fatigue load limit: 2.45 kN
Limiting speed for grease lubrication: 9500 rpm
Limiting speed for oil-air lubrication: 15000 rpm
Bearing set-arrangement: TG; Three bearings for universal matching
Bearing set – preload: Light preload
Weight: 0.87 kg
