SKF 7312 Becbj Angular Contact Ball Bearing
New
In stock6 unitsReady to ship
Angular Contact Ball Bearing
SKF 7312BECBJ single row angular contact ball bearing with 60 mm bore, 40° contact angle, dynamic load rating of 104 kN, and P6 tolerance class for high-speed industrial applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SKF 7312BECBJ Angular Contact Ball Bearing
The SKF 7312BECBJ is a single row angular contact ball bearing designed to accommodate combined radial and axial loads at high speeds. With a 40° contact angle and precision manufacturing, it delivers reliable performance in demanding industrial applications.
Manufacturer: SKF
Type: Single Row Angular Contact Ball Bearing
Model: 7312BECBJ
Load Ratings & Performance
Design & Accuracy
| Bore Diameter (d) | 60 mm |
| Outer Diameter (D) | 130 mm |
| Width (B) | 31 mm |
| Contact Angle | 40 Degrees |
| Basic Dynamic Load Rating (Cr) | 104 kN |
| Basic Static Load Rating (C0r) | 76.5 kN |
| Fatigue Load Limit | 3.2 kN |
| Limiting Speed | 6700 rpm |
| Reference Speed | 6300 rpm |
| Cage | Steel Sheet Metal |
| Matched Arrangement | No |
| Universal Matching Bearing | Yes |
| Axial Internal Clearance | Not Applicable |
| Tolerance Class | Class 6 (P6) |
