SKF NU 220 ECP Cylindrical Roller Bearing
New
In stock1 unitReady to ship
Cylindrical Roller Bearing
SKF NU 220 ECP single-row cylindrical roller bearing with optimized internal design, polyamide cage, and high radial load capacity. Ideal for heavy-duty gearboxes and industrial motor applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SKF NU 220 ECP Cylindrical Roller Bearing
The SKF NU 220 ECP is a single-row cylindrical roller bearing designed to accommodate high radial loads and high-speed operation in demanding industrial applications.
Manufacturer: SKF
Type: Single-Row Cylindrical Roller Bearing
Model: NU 220 ECP
Suffix Explanation:
Recommended for heavy-duty gearboxes, industrial motors, and high-radial-load machinery.
Please contact us via Ask for assistance with any inquiries.
| Bore Diameter (d) | 100 mm |
| Outer Diameter (D) | 180 mm |
| Width | 34 mm |
| Dynamic Load Rating | 285 kN |
| Static Load Rating | 305 kN |
| Fatigue Load Limit | 36.5 kN |
| Reference Speed | 4000 r/min |
| Limiting Speed | 4500 r/min |
| Bearing Design | NU |
| E | Optimized Internal Design |
| C | Cage Centered on the Inner Ring |
| P | Glass Fiber Reinforced Polyamide 6.6 Cage, Lightweight Window-Type |
