SKF NU 2306 ECP Cylindrical Roller Bearing
Used
Available on request
Cylindrical Roller Bearing
SKF NU 2306 ECP Cylindrical Roller Bearing features 30 mm bore and 72 mm outer diameter, supporting high radial loads and operating speeds up to 12000 rpm.
New
In stock
This product is also available brand new
View New Version →
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SKF Cylindrical Roller Bearing “ NU 2306 ECP
The SKF NU 2306 ECP Cylindrical Roller Bearing is designed for high-performance applications requiring reliable radial load support and high-speed operation. With a non-metallic cage, it ensures smooth operation under varying load conditions.
Manufacturer: SKF
Type: Cylindrical Roller Bearing
Model: NU 2306 ECP
| Bore Diameter (d) | 30 mm |
| Outer Diameter (D) | 72 mm |
| Width | 27 mm |
| Dynamic Load Rating (Cr) | 83 kN |
| Static Load Rating (C0r) | 75 kN |
| Fatigue Load Limit | 9.65 kN |
| Reference Speed | 11000 rpm |
| Limiting Speed | 12000 rpm |
| Cage | P, Non-metallic |
