SKF YAR 209-112-2F Insert Ball Bearing

Manufacturer: SKF

Type: Insert bearing with set screw locking and extended inner ring

Model: YAR209-112-2F

Bore Diameter d: 44.45 mm

Outer diameter D: 85 mm

Width of inner ring B: 49.2 mm

Width of outer ring C: 22 mm

Basic load ratings:

Dynamic C: 33200 N

Static C₀: 21600 N

Fatigue load rating: 915 N

Limiting speed: 4300 rpm

Inner ring extension: on both sides

Outer ring type: Spherical

Retaining feature, inner ring: Set screws

Sealing: Seal and flinger on both sides

Bore type: Cylindrical
