SNR 2309K-G15-J30 Self-Aligning Ball Bearing
New
In stock1 unitReady to ship
Self-Aligning Ball Bearing
The SNR 2309K-G15-J30 bearing features a 45 mm bore, tapered 1:12 K-type bore, and J30 internal clearance. With a G15 reinforced polyamide cage, it™s ideal for misalignment-prone industrial setups.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
SNR 2309K-G15-J30 Self-Aligning Ball Bearing
The SNR 2309K-G15-J30 is a precision-engineered self-aligning ball bearing designed for applications that demand smooth operation under misalignment conditions. With a K-type tapered bore (1:12), G15 glass fiber reinforced polyamide cage, and J30 clearance (larger than normal), it ensures reduced friction, stability, and adaptability in dynamic environments.
Manufacturer: SNR
Type: Self-Aligning Ball Bearing
Model: 2309K-G15-J30
| Bore Diameter (d) | 45 mm |
| Outer Diameter (D) | 100 mm |
| Width (B) | 36 mm |
| Cage | G15, Glass Fiber Reinforced Polyamide |
| Clearance | J30, Internal Clearance Larger Than Normal |
| Bore Type | K, Tapered Bore, Taper 1:12 |
