SNR 6010.FT150 Deep Groove Ball Bearing
Manufacturer: SNR
Type: Deep Groove Ball Bearing, Topline Series
Model: 6010 FT150
Dimensions
Bore Diameter d: 50 mm
Outer diameter D: 80 mm
Width B: 16 mm
Dynamic Cr: 24200 N
Static C0r: 16600 N
Limiting Speed – Grease: 5000 rpm
Limiting Speed – Oil: 5000 rpm
Radial clearance class: C3
Operating temperature: -40 °C … 150°C
Cage material: Pressed steel cage
Enclosure: Double Sealed
Seal Type: Contact
Seal Material: Viton
