Telco MPA 21 A 603 Multiplexed Amplifier

Manufacturer: TELCO

Type: Multiplexed Amplifier

Model: MPA 21 A 603

Part No.: 0453111300

Supply Voltage: 24 V dc

Current Consumption: Max. 3 VA

Response Time ton / toff, Transistor     : 45 ms / 45 ms

Output, Transistor: 40 mA / 30 V dc

Delay Time ton / toff: 0 – 3 sec, adjustable

Number of Channels: 2

Sensing Range : 45 m

Sensitivity Adjustment: Manual

Output: 2 individual NPN/PNP

Timer: On/Off Delay

Housing: 11-pole DIN socket

Sealing Class: IP 40

Operation Temperature : -10 … +50 °C
