Telemecanique VW3A7701 Braking Resistor
Braking Resistor
Telemecanique Schneider VW3 A7 701 braking resistor, 100 Ohms, 50 W, IP20, designed for Altivar variable speed drives with integrated thermal protection.Telemecanique Schneider VW3 A7 701 Braking Resistor
The Telemecanique Schneider VW3 A7 701 braking resistor is designed for use with Altivar variable speed drives. It provides effective braking performance, controlled energy dissipation, and thermal protection for industrial drive systems.
Manufacturer: Telemecanique Schneider
Type: Braking Resistor
Model: VW3 A7 701
Code: 02 3111628100 / 0231167 18100 / 19.17
Range: Altivar
Electrical Connection:
Range Compatibility
Altivar 312, Altivar 61, Altivar 312 Solar, Altivar 32, Altivar 31C
Product Compatibility
ATV31C018M2, ATV31C037M2, ATV31C037N4, ATV31C055M2, ATV31C055N4, ATV31C075M2, ATV31C075N4, ATV31CU11M2, ATV31CU11N4, ATV31CU15M2, ATV31CU15N4, ATV31CU22N4, Variable Speed Drive ATV310 at 1.5 kW, Variable Speed Drive ATV310 at 2.2 kW, ATV31CU30N4, ATV31CU40N4
| Resistance | 100 Ohms |
| Power | 50 W |
| Protection Class | IP20 |
| Average Power Available | 50 W at 50 °C / 58 W at 40 °C |
| Terminal, Connection Capacity | ‰¤ 1.5 mm² / AWG 16 (Temperature Control Switch) |
| Terminal, Connection Capacity | ‰¤ 4 mm² / AWG 28 (Drive) |
| Temperature Controlled Switch Contact Resistance | 60 µOhm |
| Protection Type | Thermal Protection via Drive or Temperature Control Switch at 120 °C |
| Width | 95 mm |
| Height | 293 mm |
| Depth | 95 mm |
| Ambient Air Temperature for Operation | 0 / 50 °C |
