Telemecanique XPS-DME 1132 Safety Relay

Manufacturer: Telemecanique
Type: Safety Relay
Model: XPSDME1132

Supply voltage: 24 V DC
Consumption power: < 3.5 W
Number and type of safety circuits: 2 N/O
Max. total thermal current: 12 A
Output fuse protection: 4 A gG or 6 fast acting
Response time on input opening: < 20 ms
Control unit voltage and current: 28 V/8 mA
Rated impulse withstand voltage (Uimp): 4 kV
Rated insulation voltage (Ui): 300 V
Ambient air temperature: -10 … 55°C
Degree of protection: Terminals: IP 20, enclosure: IP 40
Connection: Captive screw clamp terminals
Standard: IEC 60947-5-1
