Turck FCS-G1/2A4-N4-H1141 Flow Monitoring

Manufacturer: TURCK
Type: Flow Monitoring
Model: FCS-G1/2A4-N4-H1141
Id. No.: 6870303

Mounting: Immersion sensor
Water Operating Range: 1…150  cm/s
Oil Operating Range: 3…300  cm/s
Stand-by time: typ. 8 s (2…15 s)
Switch-on time: typ. 2 s (1…15 s)
Switch-off time: typ. 2 s (1…15 s)
Temperature jump, response time: max. 12 s
Medium temperature: -20…+80  °C
Protection class: IP67
Design: Immersion
Housing material: Stainless steel, 1.4571 (AISI 316Ti)
Sensor material: Stainless steel, 1.4571 (AISI 316Ti)
Max. tightening torque of housing nut: 30 Nm
Electrical connection: Connector, M12 × 1
Process Pressure: 100  bar
Process connection: G 1/2″
