Turck WKC4T-P7X2-5/TXL Actuator AND Sensor Cable

Manufacturer: TURCK
Type: Actuator and Sensor Cable
Model: WKC4TP7X25/TXL
Part No.: 6626205

Rated Voltage: 30 V DC
Rated Current: 4 A
LED Display: Dual LED
Display Operating Voltage: LED, Green
Display Switch State: LED, Yellow
Electrical Connection: Female Connector M12x1, 3-Pin, Angled, A-Coded
Material:
– Contacts: Brass, CuZn, Gold-Plated
– Contact Carriers: Plastic, TPU, Black
– Connector Body: Plastic, TPU, Translucent
– Coupling Nut/Screw: Brass, CuZn, Nickel-Plated
– Seal: Plastic, FPM/FKM
Cable Jacket: PUR, Black
Cable Diameter, Length: 4.1 mm, 5 m
Connector Diameter, Length: 15, 32 mm
Protection Class: IP67/ IP69K
Ambient Temperature: -25 … 60 °C
