Wago 750-501 Channel Digital Output
Channel Digital Output
The Wago 750-501 Channel Digital Output features 2 digital outputs, 24 V DC signal voltage, and up to 0.5 A output current. Ideal for industrial automation with 5 kHz switching frequency and reliable performance.Wago 750-501 Channel Digital Output
The Wago 750-501 Channel Digital Output is a versatile and high-performance output module designed for use in industrial automation systems. With 2 digital outputs operating at 24 V DC, this module offers reliable and fast switching for a wide range of applications. It supports a maximum switching frequency of 5 kHz, ensuring efficient and rapid response in demanding environments. The module also provides an output current of up to 0.5 A, making it suitable for controlling various industrial devices.
Manufacturer: Wago
Type: Channel Digital Output
Model: 750-501
This module is perfect for applications that require fast switching, robust performance, and the ability to control different types of industrial equipment, offering reliable and accurate output for automation systems.
| Type of Signal Voltage | 24 V DC |
| Current Consumption | 3.5 mA |
| Number of Digital Outputs | 2 |
| Switching Frequency (Max.) | 5 kHz |
| Output Current (Max.) | 0.5 A |
| Isolation Voltage | 500 V |
| Cross Sections | 0.08 mm² / 2.5 mm² / AWG 28 / 14 |
| Stripped Lengths, 750/753 Series | 8 / 9 mm, 9 / 10 mm |
| Width | 12 mm |
