Wago 750-881 Controller Ethernet Module
New
In stock1 unitReady to ship
ETHERNET Controller The WAGO 750-881 is a 32-bit ETHERNET controller with 24 V DC supply and 10/100 Mbit/s communication, designed for PLC automation, remote control, and industrial networking applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| Part No. | 750-881 |
| Ref No | 1001886870/1418100807340334 |
| System Supply Voltage | 24V DC |
| Ethernet protocol | HTTP /BootP /DHCP /DNS /SNTP/ FTP /SNMP Visualization: Web-Visu |
| CPU | 32 bits |
| Programming languages per IEC 61131-3 | Instruction List (IL) Ladder Diagram (LD) Function Block Diagram (FBD), Continuous Function Chart (CFC) Structured Text (ST) Sequential Function Chart (SFC) |
| Programming environment | WAGO-I/O-PRO V2.3 |
| Configuration options | WAGO-I/O-CHECK/ Web-based management |
| Baud rate (communication/fieldbus 1) | 10/100 Mbit/s |
| Baud rate | 10/100 Mbit/s |
| Transmission medium (communication/fieldbus) | Twisted Pair S-UTP; 100 Ω; Cat. 5; Line length (max.): 100 m |
| Transmission performance | Class D acc. to EN 50173 |
| Program memory | 1024 kByte |
| Data memory | 512 kByte |
| Software non-volatile memory | 32Kbytes |
| Number of modules per node max. | 250 |
| Number of I/O modules without bus extension max. | 64 Input and output process image (Fieldbus) max. :1020 Worte/1020 Worte |
| Number of outgoing power jumper contacts | 3 |
| Isolation | 500 V system/supply |
| Connection data Connection technology | communication/fieldbus EtherNet/IP: 2 x RJ-45; Modbus TCP/UDP: 2 x RJ-45 |
| Applications | PLC-based automation systems/Remote monitoring and control/Industrial Ethernet networking/Modbus TCP/UDP communications |
| Width | 61.5 mm |
| Height | 71.9 mm |
| Height from upper-edge | of DIN-35 rail 64.7 mm / 2.547 inch Depth: 100 mm |
| Stock key | CON-003 |
| Condition | New |
| SKU | 1100799 |
| Weight | 0,19 |
