Weidmuller RSO 30/DV 5-24V Cc/Sc Solid-State Relay Module
New
In stock16 unitsReady to ship
Solid-State Relay Module Weidmüller celduc RS series solid-state relay module with 5-24 V DC rated control voltage, 3 A continuous current and fast switching performance for industrial control applications.
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed
| Brand | celduc |
| MNR | SKA 20420 |
| Code | 9443100000 |
| Series | RS |
| Input Voltage | 4 to 30 VDC |
| Rated control voltage | 5...24 V DC |
| Rated switching voltage | 2...60 V DC |
| Impulse withstands voltage | 4 Kv |
| Output Voltage | 230 VAC |
| Continuous current | 3 A |
| Switch-on delay | < 300 µs |
| Switch-off delay | < 1 ms |
| Wire connection method | Screw connection |
| switching frequency | max. 500 Hz |
| Operating temperature | -25 °C...40 °C |
| Dimensions | 11x80x54 mm |
| Condition | New |
| Stock key | JO-004 |
| SKU | 1098376 |
| Weight | 0,04 |
