Wenglor XW100PA3 Retro-Reflex Sensor Universal

In stock1 unitReady to ship

The Wenglor XW100PA3 features a 14,000 mm range, PNP output, laser light source, and IP67 protection, making it ideal for precise long-range detection in industrial systems.

Manufacturer
WENGLOR
SKU
1059412
Category
Sensors
Condition
Used
Share
Massive Inventory
Global Shipping
Expert Support
Quality Guaranteed

Wenglor XW100PA3 Retro-Reflex Sensor Universal

The Wenglor XW100PA3 Retro-Reflex Sensor Universal is a high-performance sensor designed for accurate and reliable detection in industrial automation systems. With a sensing range of up to 14,000 mm, this sensor offers superior long-range detection. It features PNP switching output and supports both Normally Closed (NC) and Normally Open (NO) configurations for versatility. The laser light source, with a wavelength of 655 nm, ensures precise measurement, while the sensor’s IP67 rating provides dust and water protection, making it ideal for use in harsh environments. Its fast response time of 167 µs and switching frequency of 3 kHz make it highly effective in high-speed applications.

  • Manufacturer: Wenglor
  • Type: Retro-Reflex Sensor Universal
  • Model: XW100PA3

Technical Specifications:

  • Supply Voltage: 10 / 30 V DC
  • Current Consumption: 30 mA
  • Output: NC Normally Closed + NO Normally Open
  • Switching Output: PNP
  • Connection: M12 × 1; 4-pin
  • Setting Method: Potentiometer
  • Switching Frequency: 3 kHz
  • Response Time: 167 µs
  • Range: 14,000 mm
  • Reference Reflector/Reflector Foil: RQ100BA
  • Smallest Recognizable Part: 100 µm
  • Switching Output Voltage Drop: 2.5 V
  • PNP Switching Output/Switching Current: 200 mA
  • Protection Class: III
  • Light Source: Laser (red)
  • Wavelength: 655 nm
  • Degree of Protection: IP67
  • Housing Material: Stainless steel, V2A (1.4305 / 303) / Plastic, PBT
  • Temperature Range: -25 / 60 °C

The Wenglor XW100PA3 Retro-Reflex Sensor Universal is a versatile, high-performance sensor designed for precise long-range detection in various industrial environments. With robust protection against dust and water, it excels in challenging conditions while maintaining high-speed functionality.
