HZ0B08G Filter Regulator
В наличии1 единицаГотово к отправке
Фильтр-регулятор HZ0B08G — высокопроизводительный пневматический компонент для регулирования давления воздуха и фильтрации. С фильтрацией 20 микрон, расходом 1000 Nl/min и регулируемым диапазоном давления от 0,5 до 8,5 бар обеспечивает эффективную и стабильную работу в системах сжатого воздуха.
100020AdjustableAirCompressedCondensationdrainfilterflowG1/4G1/8IndustrialManualMicronNl/minPneumaticPressureRateregulatorThread
Огромный ассортимент
Глобальная доставка
Экспертная поддержка
Гарантия качества
Filter Regulator HZ0B08G
The HZ0B08G Filter Regulator is designed for efficient air pressure regulation and filtration in pneumatic systems. With a filtration rating of 20 micrometers and a maximum inlet pressure of 10 bar, it ensures clean and stable compressed air flow. Its compact design, manual condensation drain, and adjustable pressure control make it ideal for various industrial applications.
- Type: Filter Regulator
- Model: HZ0B08G
Technical Specifications
- Filtration Rating: 20 micrometers
- Flow Rate: 1000 Nl/min
- Max. Inlet Pressure: 10 bar
- Pressure Adjustment by Relieving: 0.5 to 8.5 bar
- Fluid: Compressed air
- Min./Max. Temperature: 5 to 60°C
- Condensation Drain Capacity: 12 cm³
- Condensation Drain: Manual
- Thread: G1/8, G1/4
