BAUMER IFRM 08P37A3/S35L Inductive PROXIMITY SENSOR
Neu
Auf Lager5 EinheitenVersandbereit
Inductive Proximity Sensor BAUMER IFRM 08P37A3/S35L sensor with PNP output, infrared light source, adjustable sensitivity, and IP67 protection for industrial automation applications.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
| Art No | 10139455 |
| Mounting type | Flush |
| Nominal sensing distance Sn | 2 mm |
| Hysteresis | 3 … 20 % of Sr |
| Output indicator | 3 port LED red |
| Switching frequency | 5 kHz |
| Voltage supply range +Vs | 10 … 30 VDC |
| Class | 2 |
| Current consumption max. (no load) | 12 mA |
| Output circuit | PNP break function (NC) |
| Voltage drop Vd | <2 VDC |
| Output current | 200 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Cylindrical threaded |
| Material (sensing face) | PBT |
| Housing material | Stainless steel |
| Dimension | 8 mm |
| Housing length | 36 mm |
| Connection types | Connector M8 |
| Tightening torque max. | 10 Nm (Front: 7 Nm) |
| Operating temperature | -25 … +75 °C |
| Protection class | IP 67 |
| Stock key | CON003 |
| Condition | New |
| SKU | 1100937 |
| Weight | 0,01 |
