Beckhoff BX3100-0000 BUS Terminal Controller FOR Profibus-DP

Name: BECKHOFF BX3100-0000 BUS TERMINAL CONTROLLER FOR PROFIBUS-DP
SKU: 1083008
Availability: LimitedAvailability

Beckhoff-bx3100-0000-bus-terminal-controller-for-profibus-dp(new)

Beckhoff-bx3100-0000-bus-terminal-controller-for-profibus-dp(new)-1

Beckhoff-bx3100-0000-bus-terminal-controller-for-profibus-dp(new)-2

Beckhoff-bx3100-0000-bus-terminal-controller-for-profibus-dp(new)-3

Beckhoff-bx3100-0000-bus-terminal-controller-for-profibus-dp(new)-4

Neu

Auf Lager2 EinheitenVersandbereit

Bus Terminal Controller

Beckhoff BX3100-0000 controller for PROFIBUS-DP with 16-bit processor, TwinCAT PLC software, diagnostic display, joystick switch, 2040 digital and 1024 analog I/O, and 24 VDC supply.

Hersteller

BECKHOFF

SKU

1083008

Kategorie

PLC Modules

Zustand

Neu

Automation Beckhoff BUS BX3100 BX3100-0000 Controller Industrial PLC Profibus-DP terminal

Umfangreiches Lager

Weltweiter Versand

Experten-Support

Qualitätsgarantie

Beckhoff BX3100-0000 Bus Terminal Controller for PROFIBUS-DP

The Beckhoff BX3100-0000 is a compact bus terminal controller designed for PROFIBUS-DP networks. Equipped with a 16-bit micro-controller, diagnostic display, and joystick switch for parameterization, it ensures reliable control and efficient communication in automation systems.

Manufacturer: Beckhoff

Type: Bus Terminal Controller for PROFIBUS-DP

Model: BX3100-0000

Serial No.: 11382

Processor	16-bit micro-controller
Diagnostic LEDs	2 x power supply, 2 x K-Bus
Display	FSTN 2 x 16 lines, illuminated
Switch	Joystick switch for parameterization and diagnosis
Clock	Battery-powered internal clock
Configuration/Programming Software	TwinCAT PLC
Fieldbus Interface	PROFIBUS DP
Fieldbus Connection	D-sub, 9-pin
SSB	CANopen-based sub-bus interface
Terminal Bus (K-Bus)	64 (255 with K-bus extension)
Digital Peripheral Signals	2040 inputs/outputs
Analog Peripheral Signals	1024 inputs/outputs
Configuration	Via TwinCAT or the controller
Max. Number of Bytes (Fieldbus)	Depending on fieldbus
Max. Number of Bytes (PLC)	2048 input data, 2048 output data
Power Supply (Us)	24 VDC (-15% / +20%)
Input Current (Us)	180 mA + (total K-bus current)/4
Starting Current (Us)	Approx. 2.5 x continuous current
K-Bus Current (5 V)	Maximum 1450 mA
Power Contact Voltage (Up)	24 VDC max.
Power Contact Current Load (Up)	Max. 10 A
Dielectric Strength	500 V (power contact/supply voltage/Ethernet/fieldbus)
