Coel F71B4 Brake Motor
Gebraucht
Auf Lager1 EinheitVersandbereit
Bremsmotoren Der COEL F71B4 Bremsmotor bietet hohe Effizienz mit einer Motordrehzahl von 1390/1670 U/min, 0,37 kW Leistung und Schutzart IP54 für den industriellen Einsatz.
0.371390/1670BrakeClassDeltaEfficiencyFHighIndustrialIP54kWmotorMotorsProtectionSpeedStarThermalvoltage
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
COEL F71B4 BRAKE MOTORS
The COEL F71B4 Brake Motor is designed for high-performance applications, offering reliable and efficient operation in various industrial environments. With a motor speed of 1390/1670 rpm and motor power of 0.37 kW, this motor ensures precision control and optimal performance. It features a thermal class of F and protection class IP54, making it suitable for demanding applications.
Manufacturer: Coel
Type: Brake Motors
Model: F71B4
Technical Specifications
- Motor Speed [r/min]: 1390/1670
- Motor Power [kW]: 0.37/0.37
- Rated Voltage [V] Delta: 220-240/260-280
- Rated Voltage [V] Star: 400-415/440-480
- Nominal Current [A]: 2.3/1.3
- Motor Frequency [Hz]: 50/60
- Cos Phi: 0.70
- Thermal Class: F
- Duty: S1
- Protection Class [IP]: 54
- Brake Voltage [V]: 230/400/50
