Fafnir 3MM9116WIDUM Super Precision Angular Contact Ball Bearing

Name: FAFNIR 3MM9116WIDUM SUPER PRECISION ANGULAR CONTACT BALL BEARING
SKU: 1057027
Availability: LimitedAvailability

fafnir-3MM9116WIDUM-super-precision-angular-contact-ball-bearing-(new)

fafnir-3MM9116WIDUM-super-precision-angular-contact-ball-bearing-(new)-1

fafnir-3MM9116WIDUM-super-precision-angular-contact-ball-bearing-(new)-2

fafnir-3MM9116WIDUM-super-precision-angular-contact-ball-bearing-(new)-3

fafnir-3MM9116WIDUM-super-precision-angular-contact-ball-bearing-(new)-4

fafnir-3MM9116WIDUM-super-precision-angular-contact-ball-bearing-(new)-5

fafnir-3MM9116WIDUM-super-precision-angular-contact-ball-bearing-(new)-6

Neu

Auf Lager2 EinheitenVersandbereit

Super-Präzisions-Kugellager mit Winkellagerkontakt

Hersteller

FAFNIR

SKU

1057027

Kategorie

Angular Contact

Zustand

Neu

80 Angular Ball bearing bearings Contact Fafnir mm Precision shaft spindle Super

Umfangreiches Lager

Weltweiter Versand

Experten-Support

Qualitätsgarantie

Manufacturer: FAFNIR
Type: SUPER PRECISION ANGULAR CONTACT BALL BEARING
Model: 3MM9116WI DUM
Alternative part number: 7016

Item Per Set: 2
Dimensions:
Bore Diameter d: 80 mm
Outer diameter D: 125 mm
Width C: 22 mm
Construction: WI angular contact; low shoulder on outer ring
Contact angle α: 25 °
Mounting: Duplex pairs of bearings, medium
Level of Precision: Super precision, ABEC-7
Basic load ratings:
Dynamic C_r: 61400 N
Static C_0r: 52500 N
Speed rating: 9300 RPM
Operating Speed (DUM):
Grease: 5580 RPM
Oil: 9450 RPM
Preload (DUM): Medium preload
Cage: Phenolic cage
