Festo 1320826 Bellows Gripper

Manufacturer: FESTO

Type: BELLOWS GRIPPER

Model: DHEB-27-E-U-S-P

Part No.: 1320826

Media: Compressed Air

Size: 27

Stroke Of Bellows: 12 mm

Min. Diameter To Be Gripped: 28 mm

Max. Diameter To Be Gripped: 37 mm

Mode Of Operation: Single-acting Closed

Operating Pressure: 4 bar … 8 bar

Resetting Pressure max.: 1 bar

Fluid Temperature Range: 5 … 60°C

Weight: 100 g
