Hiwin QHW30CC Linear Guideway Block
Neu
Auf Lager12 EinheitenVersandbereit
119,01$
Schwerlast-Linearlagerblock von HIWIN mit SynchMotion-Technologie, 30 mm Größe und hohen dynamischen/statischen Lastbewertungen, ideal für Präzision und Haltbarkeit in anspruchsvollen industriellen Bewegungssystemen.
30BlockGuideGuidewayHeavyHiwinIndustrialLinearLoadmmMotionmountPrecisionQHQHW30CCrailSeriesSynchMotionTop
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
HIWIN QHW30CC LINEAR GUIDEWAY BLOCK
The HIWIN QHW30CC is a heavy-duty linear guideway block designed for high-load applications, offering smooth motion and superior stability. Part of the QH Series with SynchMotion Technology, it ensures low noise, low friction, and improved lubrication distribution for long-lasting performance in demanding environments.
Manufacturer: HIWIN
Type: Linear Guideway Block
Model: QHW30CC
MRN: QHW30CC 1902E4-40000
| Size | 30 mm |
| Total Height H | 42 mm |
| Block Width W | 90 mm |
| Block Length L | 97.4 mm |
| Block Height | 36 mm |
| Distance Between Holes | 72 mm, 52 mm |
| Basic Load Rating - Dynamic Cr | 46.4 kN |
| Basic Load Rating - Static C0r | 48.1 kN |
| Series | QH Series (Heavy Load Type, SynchMotion Technology) |
| Block Mounting | C (Top or Bottom) |
| Load Type | C (Heavy Load) |
