INA Natv 35 PP X Yoke Type Track Roller

Manufacturer: INA Schaeffler
Type: Yoke Type Track Roller
Model: NATV 35 PP X

Dimensions
Bore Diameter d: 35 mm
Outer diameter D: 72 mm
Width of Bearing B: 29 mm
Basic dynamic load rating: 32,000 N
Basic static load rating: 72,000 N
Fatigue load limit, radial: 10,300 N
Speed on permanent grease lubrication: 750 1/min
Permissible static load, radial: 72,000 N
Permissible dynamic load outer ring, radial: 62,000 N
Sealing: Three-stage sealing by plastic axial plain washer on both sides
