Leuze BPS 307I SM 100 BAR Code Positioning System

Manufacturer: Leuze
Type: BAR CODE POSITIONING SYSTEM
Model: BPS 307I SM 100
Part No.: 50125679

Series: BPS 300i
Supply voltage: 18 … 30 V, DC
Current: less than 250 mA
Measuring range (measurement on reflecting foil): 0 … 10,000,000 mm
Measurement value output: 0.05 … 2 ms
Power Consumption (no load): 3.7 W
Pulse duration: less than 150 μs
Wave length: 655 nm
Laser power Max.: less than 1 mW
Max. traverse rate.: 10 ms
Housing material: Metal
Lens cover material: Glass
Operating temperature range: -5 … 50°C
Laser protection class: 2/LPS
Type of display: LED
Degree of protection: IP65
Dimension (W x H x L): 100 mm x 108.7 mm x 48.3 mm

ATTACHEMENT:  LEUZE  MS 307 MODULAR CONNECTION UNI

Manufacturer: Leuze
Type: MODULAR CONNECTION UNIT
Model: MS 307
Part No.: 50126130

Supply voltage: 18 … 30 V, DC
Number of connections: 3
Thread size: M12
Type: Male
Material: Metal
No. of pins: 5 -pin
Dimension (W x H x L): 64 mm x 33.5 mm x 43.5 mm
Housing material: Metal, Diecast aluminum
