Novotechnik IP6501 A502 Angular Potentiometer

NOVOTECHNIK IP6501 A502 Angular Potentiometer

The NOVOTECHNIK IP6501 A502 is a precision angular potentiometer engineered for accurate rotary position measurement in industrial environments. With a sealed 6 mm stainless steel shaft, conductive plastic resistance element, and precious metal multi-finger wiper, this sensor ensures long-lasting, high-resolution feedback. Its aluminum anodized housing and stainless steel ball bearings offer excellent mechanical durability. With an IP65 protection rating and operating temperature range from -40°C to +100°C, it is ideal for robust applications requiring reliable angular position sensing.

• Manufacturer: NOVOTECHNIK
• Type: Angular Potentiometer
• Model: IP6501 A502
• Part No.: 001001 / 033517 / 0080

Technical Specifications:

• Max. Permissible Applied Voltage: 42 V
• Shaft Diameter: 6 mm
• Shaft Type: Sealed Shaft
• Max. Wiper Current (in malfunction): 10 mA
• Case Material: Aluminum, anodized
• Shaft Material: Stainless steel
• Bearings: Stainless steel ball bearings
• Resistance Element: Conductive plastic
• Wiper Assembly: Precious metal multi-finger wiper
• Electrical Connection: 5-pin connector
• Protection Class: IP65
• Operating Temperature: -40°C to +100°C

Applications:

• Robotics and automation
• Industrial machinery feedback systems
• Angle and position sensing
• Motion control systems
