Pepperl+Fuchs NCN20+U1+N0 Inductive Sensor

Auf Lager1 EinheitVersandbereit

Inductive Sensor

A durable and long-range inductive sensor from the VariKont series, offering reliable metal detection, NAMUR output, and high protection rating for industrial automation environments.

Hersteller
PEPPERL+FUCHS
SKU
1084397
Kategorie
Sensors
Zustand
Neu
Teilen
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie

PEPPERL+FUCHS NCN20+U1+N0 Inductive Sensor

A high-performance VariKont series inductive sensor designed for precise metal detection, extended sensing distance, and reliable operation in demanding industrial environments. Ideal for automation, control systems, and safety monitoring applications. Manufacturer: PEPPERL+FUCHS

Type: Inductive Sensor

Model: NCN20+U1+N0

Part No.: 35716S

Series: VariKont

Switching FunctionNormally Closed (NC)
Output TypeNAMUR
Rated Operating Distance (sn)20 mm
InstallationNon-flush
Assured Operating Distance (sa)0 ... 16.2 mm
Actual Operating Distance (sr)18 ... 22 mm
Reduction Factor rAl0.37
Reduction Factor rCu0.35
Reduction Factor r3040.79
Output Type2-wire
Operating Voltage (UB)8 V
Switching Frequency (f)0 ... 250 Hz
Hysteresis1 ... 15%, typ. 5%
Reverse Polarity ProtectionReverse polarity tolerant
Current Consumption (Plate Not Detected)min. 3 mA
Current Consumption (Plate Detected)‰¤ 1 mA
Switching State IndicatorLED, Yellow
StandardsEN 60947-5-6:2000, IEC 60947-5-6:1999
Ambient Temperature-25 ... 100 °C
Connection TypeScrew terminals, M20 x 1.5 cable gland, usable thread length 9.1 mm, screw-in depth max. 9.1 mm
Housing MaterialPBT
Sensing FacePBT
Degree of ProtectionIP68
DimensionsM20 x 118 mm
Explosion Proof StandardDIN 19234
