RTE SSB MAX 2000 KG Single-Ended Load Beam

Manufacturer: REVERE TRANSDUCERS

Type: Single-Ended Load Beam

Model: SSB

Part No: 799511-14-R

Applications

• Platform Scales
• Belt Scales
• Pallet Scales
• Overhead Track Scales
• On-Board Weighing
• Silo Hopper Weighing

Maximum weight limit (E max): 2000 kg

Rated Output: 2 mV/V

Input Resistance: 350±3.5 Ω

Output Resistance: 350±3 Ω

Operating Temperature: -10…40 °C

Protection Class: IP66 & IP68

Class: C3

Weight: 2.165 kg
