Siemens 1FT61058AB713TG0 AC Servomotor

Manufacturer: Siemens
Type: AC Servo Motors
Model: 1FT61058AB713TG0

Rated Voltage [V]: 284
Stall Voltage [V]: 142
Rated Torque [Nm]: 42
Stall Torque [Nm]: 47
Rated Speed [rpm]: 1500
Stall Speed [rpm]: 750
Range Stall Torque [Nm]: 14.5/50
Range Stall Current [A]: 13.8/16.7
Max. Speed [rpm]: 1900
Protection Class [IP]: 64
Insulation Class: F
Mounting Position [IM]: B5
Weight [kg]: 38,3
