Siemens 3VA9114-0RL20 Residual Current Device
Neu
Auf Lager1 EinheitVersandbereit
Residual Current Protection Module Type A The SIEMENS 3VA9114-0RL20 SENTRON residual current protection module is designed for 3VA1 circuit breakers. Featuring a 160 A current rating, 800 V operating voltage, 4-pole configuration, busbar connection, and IP40 protection, it provides reliable residual current protection for industrial and commercial electrical systems.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
| Brand Name | SENTRON |
| Accessory For | 3VA1 |
| FRAME | 160N |
| Operational Current | 160A |
| Operational Voltage | 800V |
| Rated Impulse Withstand Voltage | 8kV |
| Power loss | max. 6,1W |
| Type Of Electrical Connection | Busbar Connection |
| Frequency | 50 to 60 Hz |
| Fastening Method | Screw Fixing |
| Number Of Poles | 4 |
| Dimensions | 100x101,6x70 mm |
| Ambient Temperature | -25 To 70 °C |
| Protection Degree | IP40 |
| Standard | IEC/EN 60947-2, GB/T 14048.2 |
| Condition | New |
| Stock key | JO-004 |
| SKU | 1093378 |
| Weight | 0,77 |
