Siemens 6ES7515-2AN03-0AB0-S Central Processing Unit
Zentrale Verarbeitungseinheit (CPU) Die Siemens 6ES7515-2AN03-0AB0-S ist eine Hochleistungs-CPU aus der SIMATIC S7-1500 Serie, die für die Industrieautomation entwickelt wurde. Sie verfügt über eine Verarbeitungsgeschwindigkeit von 6 ns, zwei PROFINET-Schnittstellen und 1 MB Programmspeicher und gewährleistet Zuverlässigkeit in anspruchsvollen Automatisierungsanwendungen.
Siemens 6ES7515-2AN03-0AB0-S Central Processing Unit (CPU)
The Siemens 6ES7515-2AN03-0AB0-S is a high-performance Central Processing Unit (CPU) from the SIMATIC S7-1500 series, designed for advanced industrial automation. It delivers fast processing, robust connectivity, and efficient memory management, ensuring seamless integration into complex automation systems.
Manufacturer: Siemens
Type: Central Processing Unit (CPU)
Part No.: 6ES7515-2AN03-0AB0-S
| Series | SIMATIC S7-1500 |
| Product Type Designation | CPU 1515-2 PN |
| HW Functional Status | FS04 |
| Rated Supply Voltage | 24 V DC |
| Current Consumption (Max.) | 1.03 A |
| Power Loss | 3.6 W |
| Firmware Version | V4.0 |
| Work Memory | 1 MB for program, 4.5 MB for data |
| Screen Size | 6.1 cm |
| Number of Keys | 8 |
| Mode Buttons | 2 |
| Number of I/O Controllers (Max.) | 4 |
| SIMATIC Memory Card Slot | 1 |
| Number of Distributed I/O Systems | 64 |
| PROFINET Interfaces | 2 (2-port switch) |
| CPU Processing Time for Bit Operations | 6 ns |
| Number of Breakpoints | 8 |
| Interface (Number of Ports) | 1 |
| Operating Temperature Range | -40 to 70 °C |
| Dimensions (W x H x D) | 70 x 147 x 129 mm |
