Siemens 7NG32420AA10 Temperature Transmitter

Manufacture: Siemens
Type: Temperature Transmitter
MNR: 7NG32420AA10
Family: SITRANS TW

Universal power supply U_H: 80 … 300 V DC; 90 … 250 V AC
Output signal: 0/2 … 10 V, 0/4 … 20 mA
Power consumption: 5 VA, 5 W
Measuring Range: min. 50 °C (90°F) x 1/scaling factor
Tolerance range of mains frequency: 47 … 63 Hz
Entrance area: -120 … +1000 mV
Overload capacity of the inputs: max. ± 3,5 V
Sensor current: 180 A
Sensor break monitoring function: can be switched off
Permissible ambient temperature: -25 … +70 °C
Protection class: IP20
