SKF 3202 ATN9 Double ROW Angular Contact Ball Bearing

Manufacturer: SKF

Type: Double Row Angular Contact Ball Bearing

Model: 3202ATN9

Dimensions

Bore Diameter d: 15 mm

Outer diameter D: 35 mm

Width B: 15.9 mm

Contact angle: 30 °

Basic load ratings, radial:

Dynamic C_r: 11200 N

Static C_0r: 6800 N

Fatigue load limit: 285 N

Limiting Speed: 18000 rpm

Reference speed: 22000 rpm

Cage: Glass fibre reinforced PA66 cage, rolling element centred
