SKF NU 220 ECP Cylindrical Roller Bearing
Neu
Auf Lager1 EinheitVersandbereit
Zylinderrollenlager SKF NU 220 ECP, einreihiges Zylinderrollenlager mit optimiertem Innenaufbau, Polyamidkäfig und hoher Radiallastkapazität. Ideal für Schwerlast-Getriebe und Industrieanwendungen von Motoren.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
SKF NU 220 ECP Cylindrical Roller Bearing
The SKF NU 220 ECP is a single-row cylindrical roller bearing designed to accommodate high radial loads and high-speed operation in demanding industrial applications.
Manufacturer: SKF
Type: Single-Row Cylindrical Roller Bearing
Model: NU 220 ECP
Suffix Explanation:
Recommended for heavy-duty gearboxes, industrial motors, and high-radial-load machinery.
Please contact us via Ask for assistance with any inquiries.
| Bore Diameter (d) | 100 mm |
| Outer Diameter (D) | 180 mm |
| Width | 34 mm |
| Dynamic Load Rating | 285 kN |
| Static Load Rating | 305 kN |
| Fatigue Load Limit | 36.5 kN |
| Reference Speed | 4000 r/min |
| Limiting Speed | 4500 r/min |
| Bearing Design | NU |
| E | Optimized Internal Design |
| C | Cage Centered on the Inner Ring |
| P | Glass Fiber Reinforced Polyamide 6.6 Cage, Lightweight Window-Type |
