ROD END SKF SC 25 Gelenkkopf mit 25 mm Bohrung, Stahl/Stahl Gleitkontakt und schweißbarem zylindrischem Schaft. Entwickelt für schwere industrielle Verbindungen mit 48 kN dynamischer und 73,5 kN statischer Lastbewertung.
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie
SKF SC 25 ES ROD END
The SKF SC 25 ES Rod End is a durable and high-strength mechanical joint designed for industrial applications requiring precise motion transfer and reliable performance. Featuring a steel/steel sliding contact combination and a weldable cylindrical shank, it is ideal for heavy-duty linkages and machinery.
Manufacturer: SKF
Type: Rod End
Model: SC 25 ES
| Bore Diameter (d) | 25 mm |
| Outer Diameter (D) | 65 mm |
| Width (B) | 20 mm |
| Width, Housing Eye | 18 mm |
| Centre Height, Housing | 45 mm |
| Housing Length, Total | 78 mm |
| Sliding Contact Surface Combination | Steel/steel, standard |
| Attachment Feature, Rod End Shank | Cylindrical section, with locating pin, for welding |
| Basic Dynamic Load Rating | 48 kN |
| Basic Static Load Rating | 73.5 kN |
