Wago 787-712 Power Supply

Auf Lager1 EinheitVersandbereit

Power Supply

WAGO 787-712 EPSITRON ECO Power single-phase power supply with 24 VDC output, 60 W capacity, 2.5 A current, wide input voltage range, and compact industrial design.

Hersteller
WAGO
SKU
1074949
Zustand
Gebraucht
Teilen
Umfangreiches Lager
Weltweiter Versand
Experten-Support
Qualitätsgarantie

WAGO 787-712 Power Supply

The WAGO 787-712 from the EPSITRON ECO Power series is a compact and efficient single-phase power supply designed for reliable industrial applications. It provides stable 24 VDC output with adjustable voltage range, ensuring dependable performance across varying load conditions.

Manufacturer: WAGO

Type: Power Supply

Model: 787-712

Series: EPSITRON ECO Power

Phases1
Nominal Input Voltage (Ui nom)1 x 100 / 240 VAC / 1 x AC 110 / 240 V
Input Voltage Range1 x 90 / 264 VAC; 90 / 373 VDC
Nominal Mains Frequency Range50 / 60 Hz
Input Current (Ii)1.32 A
Inrush Current30 A
Power Factor0.5 (230 VAC)
Power Factor Correction (PFC)Passive
Mains Failure Hold-up Time20 ms (230 VAC)
Nominal Output Voltage (Uo nom)24 VDC (SELV)
Output Voltage Range22 / 28 VDC (adjustable)
Default SettingDC 24 V
Nominal Output Current (Io nom)2.5 A (24 VDC)
Nominal Output Power60 W
Deviation1 %
Residual Ripple100 mV (peak-to-peak)
Internal FuseF 2.5 A / 250 VAC
Pre-fuse (Required)External DC fuse for DC input voltage
Backup Fuse (Recommended)Circuit breaker 10 A / 16 A; Tripping characteristic: B or C
Ambient Temperature-10 °C to +70 °C
