Asco E290A387 Angle-Seat Piston Valve
नया
स्टॉक में उपलब्ध1 यूनिटभेजने के लिए तैयार
Angle-Seat Piston Valve
The Asco E290A387 is a 2/2 Normally Open piston valve from the 290 series, designed for liquid and gas control. It offers 0“16 bar working pressure, 4.9 m³/h flow capacity, and PED 97/23/EC compliance for industrial reliability.2/2290Angle-SeatAscoCompliantconnectionControlE290A387g1/2GasHighIndustrialLiquidNormallyOpenPEDPistonPressureSeriesSteamValve
विशाल भंडार
वैश्विक शिपिंग
विशेषज्ञ सहायता
गुणवत्ता की गारंटी
Asco E290A387 Angle-Seat Piston Valve
The Asco E290A387 Angle-Seat Piston Valve is a robust and reliable solution for controlling liquid and gas flow in demanding industrial environments. Belonging to the Asco 290 series, this valve provides high flow capacity, long service life, and compliance with international standards.
Manufacturer: Asco
Type: Angle-Seat Piston Valve
Model: E290A387
ID. No.: M003199961
Series: 290
Code: 1C0
| Function | 2/2 Normally Open (NO), pressure-operated valve |
| Fluid | Liquid/gas |
| Flow Coefficient (Kv) | Approx. 4.9 m³/h (~82 L/min) |
| Working Pressure Range | 0 to 16 bar |
| Pilot Pressure (air/water) | 3 to 10 bar |
| Water Steam Pressure | 10 bar at 184°C |
| Compliance | Meets PED 97/23/EC standards |
| Steam Ambient Temperature | -10 to 60°C |
| Connection | G1/2 , G1/8 |
| No. of Inlet Port | 2 |
| Diameter Size | 15 mm |
