Festo 2201471 BUS Node
नया
स्टॉक में उपलब्ध1 यूनिटभेजने के लिए तैयार
Bus Node Industrial FESTO bus node with PROFINET communication, Ethernet connectivity, IP65/IP67 protection, and reliable fieldbus integration for pneumatic automation systems.
AutomationBUSCommunicationEthernetFestoFieldbusIndustrialInterfaceIP67ModuleNetworkNodePLCPneumaticProfinet
विशाल भंडार
वैश्विक शिपिंग
विशेषज्ञ सहायता
गुणवत्ता की गारंटी
| Part No. | 2201471 |
| Fluid | Air |
| Protocol | PROFINET |
| Fieldbus Interface | Ethernet |
| Field Bus Interface, Transmission Rate | 100 Mbit/s |
| Address Volume, Inputs/Outputs Max. | 64 Byte |
| Nominal Operating Voltage | 24 V DC |
| Current Max. | 4 A |
| Power Consumption | 80 mA |
| Electrical Connection | M12x1, Plug, A-Coded |
| Material | PA |
| Protection Class | IP65/IP67 |
| Ambient Temperature | 0 … 50 °C |
| Dimensions | 40 x 91 x 50 mm |
| Stock Key | JO-004 |
| Condition | New |
| SKU | 1092959 |
| Weight | 0,10 |
