Schneider LC1G185KUEN Contactor
नया
स्टॉक में उपलब्ध3 यूनिट्सभेजने के लिए तैयार
Industrial Contactor SCHNEIDER LC1G185KUEN TeSys Giga contactor designed for industrial motor control and power switching applications with 185 A rated operational current and 1000 V AC operational voltage.
विशाल भंडार
वैश्विक शिपिंग
विशेषज्ञ सहायता
गुणवत्ता की गारंटी
| SN | 3606481921949 |
| Range | TeSys |
| Range of Product | TeSys Giga |
| Product or Component Type | Contactor |
| Device short name | LC1G |
| Contactor application | Power switching,Motor control |
| Poles description | 3P |
| [Ue] rated operational voltage | 1000 V AC 50/60 Hz , 460 V DC |
| [Ie] rated operational current | 185 A (at <140 °F (60 °C)) at <= 440 V AC-3 |
| [Uc] control circuit voltage | 100...250 V AC 50/60 Hz,100...250 V DC |
| [Uimp] rated impulse withstand voltage | 8 kV |
| Overvoltage category | III |
| [Ith] conventional free air thermal current | 305 A (at 104 °F (40 °C)) |
| Rated breaking capacity | 1610 A at 440 V |
| Auxiliary contact composition | 1 NO + 1 NC |
| Product Certifications | CB Scheme, CCC, cULus,EAC,CE,UKCA,EU-RO-MR by DNV-GL |
| Tightening torque | 159.3 lbf.in (18 N.m) |
| Height | 7.6 in (193 mm) |
| Width | 4.3 in (108 mm) |
| Depth | 7.6 in (193 mm) |
| Standard | IEC/EN 60947-4-1 |
| Ambient air temperature for operation | -13…140 °F (-25…60 °C) |
| Attached with | SCHNEIDER LAG8N113P Auxiliary contact block |
| [Ue] rated operational voltage, Auxiliary contact block | 600 V AC 25...400 Hz |
| Pole contact composition, Auxiliary contact block | 1 NO + 1 NC |
| Height, Auxiliary contact block | 2.2 in (55.8 mm) |
| Width, Auxiliary contact block | 0.6 in (15.4 mm) |
| Depth, Auxiliary contact block | 3.3 in (84.8 mm) |
| Stock Key | CON-003 |
| Condition | New |
| SKU | 1099311 |
| Weight | 4,5 |
