Spirax Sarco PP5 Pneumatic Positioner
中古
在庫あり1 ユニット即納可能
599,99$
Pneumatic Positioner
Spirax Sarco PP5 Pneumatic Positioner with adjustable amplification, 10 to 100 mm stroke range, and a protection class of IP65. Designed for precise control with air consumption ranging from 0.2 Nm3/h to 0.7 Nm3/h.
大量在庫
グローバル配送
専門的なサポート
品質保証
Spirax Sarco Pneumatic Positioner PP5
The Spirax Sarco PP5 Pneumatic Positioner is designed for precise control and regulation in pneumatic systems. It offers adjustable amplification and a wide range of stroke options, ensuring versatility and performance in demanding industrial environments.
Manufacturer: Spirax Sarco
Model: PP5
Type: Pneumatic Positioner
| Inlet Control Signal | 0.2 to 1 bar |
| Outlet Loading Signal | 0.2 to 1 bar or 0.4 to 2 bar |
| Air Consumption | 0.2 Nm3/h (supply at 1.4 bar) “ 0.7 Nm3/h (supply at 6 bar) |
| Maximum Air Flow | 3.5 Nm3/h |
| Ambient Temperature Effect | Maximum +80°C, Minimum -20°C |
| Stroke Range | 10 to 100 mm |
| Amplification | Adjustable |
| Pneumatic Connection | 1/8 inch |
| Protection Class | IP65 |
| Material Base Plate and Cover | Die cast aluminum with anti-corrosive paint |
