Chiaravalli CHS1 Screw Jack
중고
재고 있음1 단위즉시 배송 가능
스크류 잭 CHIARAVALLI CHS1 스크류 잭은 500 kg 하중 용량, 5:1 및 20:1 기어 비율, 산업용 애플리케이션을 위한 빠른 속도에서 25.5% 효율의 신뢰할 수 있는 성능을 제공합니다.
방대한 재고
글로벌 배송
전문 지원
품질 보장
CHIARAVALLI CHS1 SCREW JACK
The CHIARAVALLI CHS1 Screw Jack is designed for efficient lifting and load movement, offering high reliability and performance. With a load capacity of 500 kg and gear ratios of 5:1 and 20:1 for fast and normal speeds, this screw jack provides precise control and is built to operate in various industrial conditions.
Manufacturer: CHIARAVALLI
Type: SCREW JACK
Model: CHS1
Technical Specifications
- LOAD daN: 500 Kg
- Tpn Screw Diameter: 18 mm
- Pitch: 4 mm
- Gear Ratios:
- Fast Speed: 5:1
- Normal Speed: 20:1
- Stroke For INPUT REV:
- Fast Speed: 0.80
- Normal Speed: 0.20
- Efficiency:
- Fast Speed: 25.5 %
- Normal Speed: 23.8 %
- Case Material: G25
- Grease Type: Agip Gr Mu Ep2
- Operating Temperature: -5 to 80° C
