Danfoss 17D0023 Differential Pressure Switch
Danfoss 차압 스위치 17D0023은 0.5에서 6 bar까지 압력 설정 범위, 400 V AC 정격 전압, SPDT 스위치 출력 기능을 갖추고 있습니다. IP66 보호 등급과 -50에서 70°C 온도 범위를 제공하며 산업용 모니터링 및 제어에 이상적입니다.
Danfoss Differential Pressure Switch 17D0023
The Danfoss Differential Pressure Switch 17D0023 is designed for reliable pressure monitoring and control in a variety of industrial applications. With a pressure setting range of 0.5 to 6 bar and a maximum working pressure of 42 bar, this switch ensures precise performance even under demanding conditions. It offers a rated voltage of 400 V AC and a rated current of 4 A. The switch features a SPDT output, making it ideal for use in both monitoring and control functions. Additionally, it has an IP66 protection class, ensuring its durability and resistance to harsh environmental conditions.
Manufacturer: Danfoss
Type: Differential Pressure Switch
Model: 17D0023
Technical Specifications
- Pressure Setting Range: 0.5 / 6 bar
- Working Pressure Max.: 42 bar
- Test Pressure: 47 bar
- Rated Voltage: 400 V AC
- Rated Current: 4 A
- Switch Output: SPDT
- Pressure Connection Size: G 3/8
- Protection Class: IP66
- Temperature: -50 / 70 °C
- Dimensions: 303 x 110 x 74 mm
