Hager HIM408 Switch Disconnector
재고 있음1 단위즉시 배송 가능
Hager 스위치 절연기 HIM 408, 4극, 80 A 정격 동작 전류 및 50 kA 단락 전류. 신뢰할 수 있는 보호 기능을 갖춘 안전한 전기 차단용으로 설계되었습니다.
44155060947-380aACCurrentDisconnectionDisconnectorElectricalHagerIECImpulseIndustrialkAPolesProtectionRatedSafetyShort-CircuitSwitchUimpVvoltageWithstand
방대한 재고
글로벌 배송
전문 지원
품질 보장
Hager Switch Disconnector HIM 408
Hager Switch Disconnector HIM 408 is designed for safe and reliable electrical disconnection in industrial applications. With high performance and protection, it is built to withstand high operational currents and provide superior short-circuit protection. Below are the key technical specifications:
- Manufacturer: Hager
- Type: Switch Disconnector
- Model: HIM 408
- Part No.: 314057
Technical Data:
- No. of Poles: 4
- Type of Case: Fixed Built-In
- Number of Modules: 8
- Rated Operational Voltage (Ue): 415 V AC
- Rated Operational Current (Ie): 80 A
- Short-Circuit Current with gI-gG Fuses: 50 kA
- Rated Short-Time Withstand Current 1s: 1.5 kA
- Frequency: 50/60 Hz
- Rated Insulation Voltage (Ui): 800 V
- Rated Impulse Withstand Voltage (Uimp): 8 kV
- Total Power Loss Under In: 9.6 W
- Type of Order: Short Thumb-Grip
- Standard: IEC 60947-3
- Operating Temperature: -20 to 70 °C
