Omron H3CR-A8E 0.05S-300H Solid-State Multi-Functional Timer
신제품
재고 있음1 단위즉시 배송 가능
Omron 고체 상태 다기능 타이머 H3CRA8E, 타이머 범위 0.05초부터 300시간까지, 정격 공급 전압 100-240 V AC, IP40 보호 등급. 다양한 작동 모드를 갖춘 여러 산업용 응용에 적합합니다.
100/240AutomationIndustrialMulti-FunctionalMulti-modeOmronOperationssolid-stateSpdtTimeTime-ControlledTimerV
방대한 재고
글로벌 배송
전문 지원
품질 보장
Omron Solid-State Multi-Functional Timer H3CRA8E
Omron Solid-State Multi-Functional Timer H3CRA8E is a versatile timer designed for precise and reliable control in industrial applications. With multiple operating modes and robust features, it ensures accurate timing for a variety of tasks.
- Manufacturer: Omron
- Type: Solid-State Multi-Functional Timer
- Model: H3CRA8E
Technical Data:
- Rated Supply Voltage: 100 to 240 V AC, 100 to 125 V DC
- Nominal Voltage (Un): 250 V AC, 30 V DC
- Frequency: 50/60 Hz
- Thermal Current: 5 A
- Timer Range: 0.05s to 300h
- Rated Impulse Withstand Voltage (Uimp): 4 kV
- Standard: IEC60947-5-1, EN61812-1, VDE0435/2021, IEC60664-1 (VDE0110)
Contact Ratings:
- AC-15: 3 A, 250 V AC
- AC-13: 5 A, 250 V AC
- DC-13: 0.5 A, 30 V DC
Control Output Type:
- Time-limit: SPDT
- Instantaneous: SPDT
Operation Modes:
- ON delay
- Flicker OFF start
- Flicker ON start
- Interval
- One shot output
- No. of Pins: 8
- Ambient Temperature Operating: -10 to 55°C
- Degree of Protection: IP40
- Dimensions: 48 X 48 X 81.5 mm
